Features

1. Machined motor mounting bracket containing re-greaseable camlock ball bearings for positioning and locking pump shaft in position.


2. Ball bearings act as thrust bearings and allow accurate adjustment of impeller clearance without removing pumps from installation.


3. FUME-GARD® vapor seal minimizes emissions and protects external bearings and motor from corrosive fumes.


4. Thermoplastic cover plate customized to meet tank/sump configuration.


5. Thermoplastic columns structurally reinforced for additional strength when submerged shaft lengths are greater than 8 feet.


6. Thermoplastic sleeve isolates the stainless steel shaft from the pumped fluid.

7. The submerged inner wet bearing is made from ultra pure alumina ceramic, and the outer submerged bearing from Vanite®, pure silicon carbon. Clean process fluid or water is used to lubricate and cool the wet bearings.


8. Injection molded or fabricated thermoplastic casing, casing cover and impeller.


9. Thermoplastic closed or semi-open impeller injection molded with embedded dynamically balanced stainless steel insert keyed to shaft to assure positive drive. Vortex construction is available for handling slurries and solids laden fluids.


10. Perforated strainer basket available in broad range of thermoplastic materials
